Model |
K125 |
K135 |
|
Operating pressure, fully adjustable |
10 - 125 bar |
10 - 135 bar |
|
Max. permissible pressure |
140 bar |
150 bar |
|
Water flow |
10,5 l/min at
1400 r.p.m. |
11 l/min at
1400 r.p.m. |
|
Max. suction height |
2,5 m |
2,5 m |
|
Steel fabric high-pressure hose |
10 m |
10 m |
|
Supply voltage |
230 V, 12,5 A, 50 Hz |
230 V, 14 A, 50 Hz |
|
Connection load: Input |
P 1 - 2,9 kW |
P 1 - 3,3 kW |
|
Connection load: Output |
P 2 - 2,2 kW |
P 2 - 2,4 kW |
|
Weight |
32 kg |
32 kg |
|
Dimensions in mm |
350 x 330 x 900 |
350 x 330 x 900 |
|
| |
|
| |
|
Model |
K1150 |
|
Operating pressure, fully adjustable |
10 - 130 bar |
|
Max. permissible pressure |
150 bar |
|
Water flow |
10 l/min
at 2800 r.p.m. |
|
Steel fabric high-pressure hose |
15 m |
|
Dirtkiller |
yes |
|
Supply voltage |
230 V, 50 Hz |
|
Supply current |
12AM |
|
Connection load: Input |
P 1 - 2,8 kW |
|
Connection load: Output |
P 2 - 2,1 kW |
|
Weight |
26 kg |
|
Dimensions in mm including pulling handle |
300 x 330 x 8000 |
|
| |
|
| |
| Model |
B 13-150 |
| Working pressure |
150bar |
| Water flow |
131/min |
|
Motor |
5,5PS-4,0 kW
Petrol
Honda |
|
|
|
